Iconic Module Dual USB Charger Type A+C, 15W, 300 Series

Home ProductsSwitches and SocketsPDL IconicModule Dual USB Charger

Iconic Module Dual USB Charger Type A+C, 15W, 300 Series | Vivid White

Item Number: PDL342USB2AC-VW

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width59 mm

Height icon

Height48 mm

Embedding depth icon

Embedding depth55 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

PDL Iconic

Product or component type

USB charger

Colour tint

vivid white

Surface finish

glossy

Physical

[ue] rated operational voltage

220/240 V AC 50 Hz

Integrated connection type

  • 1 USB type A 5 V DC, maximum load current: 2.4 A
  • 1 USB type C, maximum load current: 3 A

Output current

3.1 A

Device mounting

flush

Device presentation

mechanism

Fixing mode

by clips

Type of packing

box

Sale per indivisible quantity

1

Ambient air temperature for operation

0...40 °C

Ambient air temperature for storage

0...60 °C

Relative humidity

5...90 %

Protection type

short time short-circuit protection

Number of terminals

1 with cable end

Height

48 mm

Width

59 mm

Depth

59 mm

Embedding depth

55 mm

Connections - terminals

screw terminals

Reach free of svhc

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2403023_V1

Eu rohs directive

Compliant with Exemptions

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach regulation

Free of Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant By Exemption

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

PC (polycarbonate)

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Warranty duration(in months) bmecat

18

Weee label

N/A

Weee applicability

Finished product

Type of usb power supply

USB type A + C

Main colour tint

vivid white

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.9 cm

Package 1 width

6.7 cm

Package 1 length

8.7 cm

Package 1 weight

100 g

Green premium status for reporting

Green Premium product

Total lifecycle carbon footprint

36 kg CO2 eq.

Carbon footprint of the manufacturing phase [a1 to a3]

1.020096153846154

Carbon footprint of the manufacturing phase [a1 to a3]

1 kg CO2 eq.

Carbon footprint of the distribution phase [a4]

0.019128846153846153

Carbon footprint of the distribution phase [a4]

0 kg CO2 eq.

Carbon footprint of the installation phase [a5]

0.009032115384615385

Carbon footprint of the installation phase [a5]

0 kg CO2 eq.

Carbon footprint of the use phase [b2, b3, b4, b6]

35.089999999999996

Carbon footprint of the use phase [b2, b3, b4, b6]

35 kg CO2 eq.

Sustainable packaging

Yes

Carbon footprint of the end-of-life phase [c1 to c4]

0.2244423076923077

Carbon footprint of the end-of-life phase [c1 to c4]

0.2 kg CO2 eq.

Pvc free

Yes

Halogen-free status

Product contains halogen above thresholds

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Total lifecycle carbon footprint

36.36269942307692

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

Yes

Halogen-free status

Product contains halogen above thresholds

Pvc free

Yes

End of life manual availability

N/A

Take-back

No

Warranty (in months)

18
