Standard Series, Rewireable Socket Cord Extension, 10A, 1mm², Ordinary Duty Flex Transparent
Item Number: 438-TR
Datasheet
Close
Specifications
Design
Range of product
Standard Series
Product or component type
socket-outlet
Product brand
Clipsal
Physical
Quantity per set
set of 1
Marking
without marking
Local signalling
without light indicator
[in] rated current
10 A
[ue] rated operational voltage
250 V AC
Depth
71 mm
Standards
- AS/NZS 3112
- AS 3100
- AS 3109
- AS/NZS 3122:approval number S/1
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Environmental disclosure
ENVPEP1605009
Circularity profile
N/A
Material
Material
PVC (polyvinyl chloride)
Others
Package 1 bare product quantity
1
Cover type
complete housing
Diameter
43 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
5.5 cm
Package 1 width
6.7 cm
Package 1 length
10 cm
Package 1 weight
59 g
Scip number
c6f2fabe-d5ba-4588-bd03-c90f7def1381
